Label panels and equipment with the B-432 clear polyester label material, allowing the applied surface colors to transmit around the printed label text. Print almost anywhere with a Brady handheld label maker.
| Part Number | M5-17-432-CL-BK |
| Product Number | 170873 |
| UPC | 888434593004 |
| UOM | Cartridge of 280 Labels |
| Brand Name | Brady |
| Adhesive Type | Permanent Acrylic |
| Application | Asset Tracking, Barcode Labeling, Component and Equipment Labeling, Data and Telecommunications Labeling, Electrical Labeling, General Identification, Inventory and Inspection Labeling, Warehouse Marking |
| Approval/Compliance (EMEA) | UL Recognised, CSA Accepted |
| Brady Material Number | B-432 |
| Color | Black on Clear |
| Compatible Surface Types | High Surface Energy |
| Continuous or Die-cut | Die-cut |
| Corner Type | Rounded |
| Dimensions (imperial) | 0.5 in H x 1 in W |
| Dimensions (metric) | 25,40 mm (W) x 12,70 mm (H) |
| Enables Industry Compliance (North America) | ASTM B 117, ASTM D 1000, ASTM D 2979, ASTM G 155, CSA, UL Recognized |
| Finish | Gloss |
| Height (imperial) | 0.5 in |
| Height (metric) | 12.70 mm |
| Industry | Buildings identification, Chemical, Construction, Education, Electrical, Electronics, Energy utilities, Government, Healthcare, ICT, Laboratory, Manufacturing, Process, Warehouse & logistics |
| Industry Compliance UL | UL969 |
| Lab Application | General Laboratory Identification, Well Plates |
| Lab Environment | Freezer, Autoclave |
| Label Properties | Aggressive Adhesive, Heat Resistant, Permanent Adhesive |
| Label/Tape Size (imperial) | 0.5 in H x 1 in W |
| Label/Tape Size (metric) | 12.70 mm H x 25.40 mm W |
| Material | Polyester |
| Material Type | Polyester |
| Maximum Service Temperature (°C) | 100 °C |
| Maximum Service Temperature (°F) | 212 °F |
| Minimum Service Temperature (°C) | -40 °C |
| Minimum Service Temperature (°F) | -40 °F |
| Performance Characteristics | Abrasion resistance, Fuel/Oil resistance, High heat resistance, Low temperature resistance, Solvent/Chemical resistance |
| Primary Noun, Basic Function.1 | Label |
| Print Technology | Thermal Transfer |
| Printer Compatibility | BMP51, BMP53, M511, M510 |
| Printer and Label Applications | Electrical |
| Printer supply or Pre-printed | Printer supply |
| Quantity per Roll | 280 |
| Resistance Properties | Chemical-resistant, Corrosion-resistant, Humidity-resistant, UV-resistant, Weather-resistant |
| Ribbon Series | R6000HF |
| SAP B-Number | B-432 |
| SAP Local Description | M5-17-432-CL-BK |
| Service Temperature Range (°C) | -40 °C - 100 °C |
| Service Temperature Range (°F) | -40 °F - 212 °F |
| Smart Cell | Yes |
| Surface | For smooth & textured/rough surfaces |
| Thickness (imperial) | 0.004 in |
| Thickness (metric) | 0.102 mm |
| Trade Name | ToughBond |
| Vertical Repeat (imperial) | 0.625 in |
| Vertical Repeat (metric) | 15.88 mm |
| Web Width (imperial) | 1.312 in |
| Web Width (metric) | 33.32 mm |
| Width (imperial) | 1 in |
| Width (metric) | 25.40 mm |
| Contains CA PROP 65 Substance | Yes Contains-Label not req. |
| Contains CA PROP 65 Substance (Y/N) | N |
| Contains Heavy Metal(s) | No - Does not contain |
| EU RoHS Compliance | Pass 2011/65/EU(Pass 2015/863) |
| EU RoHS Compliant | Yes |
| SDS Safety Data Sheet required | No = MSDS/SDS is not required |
