This durable and economical polymer coated cloth features repositionable rubber-based adhesive for ease of use.
| Part Number | SLDAT-1-502-10 |
| Product Number | 17019 |
| UPC | 662820170198 |
| UOM | Pack of 10000 Labels |
| Brand Name | Brady |
| Adhesive Type | Permanent Rubber Based |
| After Process | Yes, this material will work with this application |
| Application | Circuit Board Labeling, Component and Equipment Labeling, Wire and Cable Labeling |
| Board Application | Through Hole Technology - Top, After Process |
| Brady Material Number | B-502 |
| Color | Black on Yellow |
| Compatible Surface Types | Low Surface Energy |
| Continuous or Die-cut | Die-cut |
| Dimensions (imperial) | 0.5 in H x 1 in W |
| Dimensions (metric) | 25,40 mm (W) x 12,70 mm (H) |
| Enables Industry Compliance (North America) | ASTM B 117, ASTM D 1000, ASTM D 2979, ASTM G 155 |
| Finish | Matte |
| Height (imperial) | 0.5 in |
| Height (metric) | 12.70 mm |
| Horizontal Repeat (imperial) | 1.1 in |
| Horizontal Repeat (metric) | 27.94 mm |
| Label Properties | Permanent Adhesive, Repositionable |
| Label/Tape Size (imperial) | 0.5 in H x 1 in W |
| Label/Tape Size (metric) | 12.70 mm H x 25.40 mm W |
| Layout | Fan-folded, Radius Corners |
| Lines per Inch | 6 or 8 lines per inch |
| Material | Vinyl Cloth |
| Material Type | Vinyl |
| Maximum Service Temperature (°C) | 80 °C |
| Maximum Service Temperature (°F) | 176 °F |
| Maximum Wire Diameter (imperial) | 0.16 in |
| Maximum Wire Diameter (metric) | 4.06 mm |
| Minimum Application Temperature (°C) | 10 °C |
| Minimum Application Temperature (°F) | 50 °F |
| Minimum Service Temperature (°C) | -40 °C |
| Minimum Service Temperature (°F) | -40 °F |
| Minimum Wire Diameter (imperial) | 0.06 in |
| Minimum Wire Diameter (metric) | 1.52 mm |
| Primary Noun, Basic Function.1 | Label |
| Print Technology | Dot Matrix |
| Printable Area Dimensions (imperial) | 0.27 in H x 1 in W |
| Printable Area Dimensions (metric) | 25.40 mm W x 6.86 mm H |
| Printable Area Height (imperial) | 0.27 in |
| Printable Area Height (metric) | 6.86 mm |
| Printable Area Width (imperial) | 1 in |
| Printable Area Width (metric) | 25.40 mm |
| Printer Compatibility | Dot Matrix Printers |
| Printer and Label Applications | Wire & Cable |
| Printer supply or Pre-printed | Printer supply |
| Quantity per Row | 7 |
| Recommended Ribbon Series | R5000 |
| Resistance Properties | Abrasion-resistant, Chemical-resistant, Corrosion-resistant, Humidity-resistant, Oil-resistant, Smear-resistant, UV-resistant, Water-resistant |
| Ribbon Series | R2000, R5000 |
| SAP B-Number | B-502 |
| SAP Local Description | SLDAT-1-502-10 |
| Service Temperature Range (°C) | -40 °C - 80 °C |
| Service Temperature Range (°F) | -40 °F - 176 °F |
| Shape | Rectangle |
| Surface | For smooth surfaces |
| Surface Mount Technology SMT | No, this material does not work with this application |
| Thickness (imperial) | 0.0096 in |
| Thickness (metric) | 0.244 mm |
| Through Hole Technology | Top: Yes. In extreme high temperatures, testing of this material is recommended, Bottom: No |
| Trade Name | DATAB |
| Vertical Repeat (imperial) | 0.67 in |
| Vertical Repeat (metric) | 17.02 mm |
| Web Width (imperial) | 8.6 in |
| Web Width (metric) | 218.44 mm |
| Width (imperial) | 1 in |
| Width (metric) | 25.40 mm |
| Wire Diameter Range (imperial) | 0.06 in to 0.16 in |
| Wire Diameter Range (metric) | 1.52 mm to 4.06 mm |
| Contains CA PROP 65 Substance | Yes Contains-Label not req. |
| Contains CA PROP 65 Substance (Y/N) | N |
| DOT Hazardous Material | No = is not a DOT hazardous material |
| EU RoHS Compliance | Pass 2011/65/EU(Pass 2015/863) |
| EU RoHS Compliant | Yes |
| SDS Safety Data Sheet required | No = MSDS/SDS is not required |
