White glossy polyester with a permanent static dissipative adhesive and liner
| Part Number | B33-51-473 |
| Product Number | 153424 |
| UPC | 888434564271 |
| UOM | Roll of 10000 Labels |
| Brand Name | Brady |
| Adhesive Type | Static Dissipative Permanent Acrylic |
| Application | Circuit Board Labeling, Electrical Labeling, General Identification |
| Brady Material Number | B-473 |
| Color | White |
| Compatible Surface Types | High Surface Energy |
| Continuous or Die-cut | Die-cut |
| Core Diameter (imperial) | 2 in |
| Core Diameter (metric) | 50.80 mm |
| Corner Type | Rounded |
| Dimensions (imperial) | 0.25 in H x 1 in W |
| Dimensions (metric) | 25,40 mm (W) x 6,35 mm (H) |
| Enables Industry Compliance (North America) | ANSI/ESD S541-2008, ASTM B 117, ASTM D 1000, ASTM D 2979, ASTM G 155, CSA Approved, UL Recognized |
| Finish | Gloss |
| Height (imperial) | 0.25 in |
| Height (metric) | 6.35 mm |
| Horizontal Repeat (imperial) | 1.075 in |
| Horizontal Repeat (metric) | 27.31 mm |
| Indoor or Outdoor Use | Outdoor Use |
| Industry | Electronics |
| Industry Compliance UL | UL969 |
| Label Properties | Harsh Environment, Heat Resistant, Permanent Adhesive, Electrostatic Dissipative |
| Label/Tape Size (imperial) | 0.25 in H x 1 in W |
| Label/Tape Size (metric) | 6.35 mm H x 25.40 mm W |
| Material | Static Dissipative Polyester |
| Material Properties | Static-dissipative |
| Material Type | Polyester |
| Maximum Service Temperature (°C) | 180 °C |
| Maximum Service Temperature (°F) | 356 °F |
| Minimum Service Temperature (°C) | -40 °C |
| Minimum Service Temperature (°F) | -40 °F |
| Primary Noun, Basic Function.1 | Label |
| Print Technology | Thermal Transfer |
| Printer Compatibility | i3300, i5300, BBP33 |
| Printer and Label Applications | General Identification, Rating & Name Plates, Circuit Board |
| Printer supply or Pre-printed | Printer supply |
| Quantity per Roll | 10000 |
| Quantity per Row | 3 |
| Recommended Ribbon | B30-R6000 |
| Resistance Properties | Abrasion-resistant, Chemical-resistant, Corrosion-resistant, Humidity-resistant, UV-resistant, Weather-resistant |
| Ribbon Series | B30 Monocolour Series |
| SAP B-Number | B-473 |
| SAP Local Description | B33-51-473, WHITE, 1.00 in X 0.250 in |
| Service Temperature Range (°C) | -40 °C - 180 °C |
| Service Temperature Range (°F) | -40 °F - 356 °F |
| Shape | Rectangle |
| Smart Cell | Yes |
| Surface | For smooth surfaces |
| Thickness (imperial) | 0.0034 in |
| Thickness (metric) | 0.09 mm |
| Total Quantity | 10000 |
| Vertical Repeat (imperial) | 0.35 in |
| Vertical Repeat (metric) | 8.89 mm |
| Web Width (imperial) | 3.35 in |
| Web Width (metric) | 85.09 mm |
| Width (imperial) | 1 in |
| Width (metric) | 25.40 mm |
| CA Prop 65 Labeled? | Y |
| Contains CA PROP 65 Substance | Yes Contains-Label required |
| Contains CA PROP 65 Substance (Y/N) | Y |
| Contains Heavy Metal(s) | Yes - Other Heavy Metals |
| EU RoHS Compliance | Pass 2011/65/EU(Pass 2015/863) |
| EU RoHS Compliant | Yes |
| SDS Safety Data Sheet required | No = MSDS/SDS is not required |
